Home > Product > Connectors and wiring harnesses > M12 connectors&cables > M12 tee connector
M12 3Pin male/M12 3Pin female and free end、Y-type molding PUR drag chain cable、Black sheath、64D351XD-L1/L2
  • M12 3Pin male/M12 3Pin female and free end、Y-type molding PUR drag chain cable、Black sheath、64D351XD-L1/L2
  • M12 3Pin male/M12 3Pin female and free end、Y-type molding PUR drag chain cable、Black sheath、64D351XD-L1/L2
  • M12 3Pin male/M12 3Pin female and free end、Y-type molding PUR drag chain cable、Black sheath、64D351XD-L1/L2

M12 3Pin male/M12 3Pin female and free end、Y-type molding PUR drag chain cable、Black sheath、64D351XD-L1/L2

Ordering code: 64D351XD-L1/L2
Series: FCC M413-M415-0000-Y52-PH0534-XXX/XXX
  • Remarks: xxx = cable length, which can be customized as needed when ordering. The cable length is in increments of 0.5m, for example: 005=0.5m, 010=1m, 015=1.5m

Parameter Table Inquiry

Related recommendations

  • Function Parameter
  • Resource Download
  • Related Video
TypeM12 male 3 Pin conversion to M12 3Pin female connector and free end 、A-coded
Maximum supply voltage  AC UB250 V
Maximum supply voltage  DC UB250 V
Rated current2A
CableMolding
Number of conductors x conductor  cross-section3×0.34 mm²
Cable molor/materialBlack / PUR (Flexible cable)
Degree of protection as per  IEC 60529IP 67
Ambient temperature Ta PUR(-40°C~+80°C)
