| Main technical parameters |
| Protection type | IP65 |
| Protection leve | III (EN 61140) |
| Vibration resistance | IEC 60068-2-6 |
| Impact resistance | IEC 60068-2-27 |
| Rated working voltage | 18~30V DC |
| Under voltage alarm | 18 V（±0.5V at 25°C） |
| Overvoltage alarm | 30V（±0.5V at 25°C） |
| Reverse voltage protection | Support reverse voltage protection |
| Module current consumption | <150mA（24VDC） |
| Power interface | M12-A, male, 5-pin |
| Support agreement | IO-Link |
| Transmission rate | COM3=230.4kbps |
| Number of valves FAS-IOL-L1-24 | Supports up to 48-bit output and 24-bit dual solenoid valves |
| Normal output current | Single channel maximum 350mA, 8 consecutive channels maximum 1A, total current maximum 4A |
| Output driver type | NPN |
| Working temperature | -5°C...+50°C |
| Storage temperature | -40°C...+85°C |
| Dimensions (length × width × height) | 90.5*41.85*46.4 |
| Shell material | PC |
| Certification | c UL us-Certification (OL) |
