M12 12Pin、Female 90°、Single end pre cast PUR flexible cable、Black sheathed、64S491-XXX
  • M12 12Pin、Female 90°、Single end pre cast PUR flexible cable、Black sheathed、64S491-XXX
  • M12 12Pin、Female 90°、Single end pre cast PUR flexible cable、Black sheathed、64S491-XXX
  • M12 12Pin、Female 90°、Single end pre cast PUR flexible cable、Black sheathed、64S491-XXX

M12 12Pin、Female 90°、Single end pre cast PUR flexible cable、Black sheathed、64S491-XXX

Ordering code: 64S491-XXX
Series: FCC M42C-0000-1A-000-0PHC-XXX
  • Note: xxx = cable length, can be customized according to needs when ordering, cable length in 0.5m increments,  for example: 005=0.5m, 010=1m, 015=1.5m
Inquiry

Related recommendations

  • Function Parameter
  • Resource Download
  • Related Video
TypeM12 right angle female、12 Pin、A-coded
Maximum supply voltage AC UB30 V
Maximum supply voltage DC UB30 V
CableCasting
Number of conductors x conductor cross-section12×0.25 mm²
Cable color/materialBlack/PUR Flexible cable
Degree of protection as per IEC 60529IP 68
