M8 4Pin male/M12 4Pin male (D-coded)、Double end molding PVC shield non flexible cable、EtherCat network cable、Green sheath、0C3081-XXX
  • M8 4Pin male/M12 4Pin male (D-coded)、Double end molding PVC shield non flexible cable、EtherCat network cable、Green sheath、0C3081-XXX
  • M8 4Pin male/M12 4Pin male (D-coded)、Double end molding PVC shield non flexible cable、EtherCat network cable、Green sheath、0C3081-XXX
  • M8 4Pin male/M12 4Pin male (D-coded)、Double end molding PVC shield non flexible cable、EtherCat network cable、Green sheath、0C3081-XXX

M8 4Pin male/M12 4Pin male (D-coded)、Double end molding PVC shield non flexible cable、EtherCat network cable、Green sheath、0C3081-XXX

Ordering code: 0C3081-XXX
Series: FCC-M314-M414-5D-036-VXG04C-XXX
  • Note: xxx = cable length, can be customized according to needs when ordering, cable length in 0.5m increments,  for example: 005=0.5m, 010=1m, 015=1.5m
Inquiry

Related recommendations

  • Function Parameter
  • Resource Download
  • Related Video
TypeM8 straight male conversion to M12 straight male 、4 Pin
CodingA-coded/D-coded
Rated working voltage UB60 V AC/DC
Cable color/materialGreen/PVC（shield）
Degree of protection as per IEC 60529IP 67
Ambient temperature Ta-25...+85 °C
